Canon C300 MKII PL/EF Cinema EOS Cameras

The EOS C300 Mark II Digital Cinema Camera is an evolutionary 2nd generation Cinema EOS 4K camera system with a wide range of new and improved features including 4K/2K/Full HD internal and external recording (including 4K RAW output) and a new 10-bit Canon Log 2 Gamma. This powerful new camera also features an expanded dynamic range of 15 stops, improved Dual Pixel CMOS Autofocus, innovative focus assist engineering and CFast recording technology. Redesigned with the help of user input, the EOS C300 Mark II Digital Cinema Camera helps to deliver more creative flexibility for professional studio motion picture production applications, as well as independent productions, TV dramas, commercials, news features, sports and more.

Category:

Product Description

SENSOR TYPE

  • CMOS Sensor (single-panel) equivalent to Super 35mm

SENSOR SIZE

  • Super 35: 24.6 x 13.8mm effective size / 6.4 x 6.4µm pixel pitch

SCANNING SYSTEM

  • Progressive

FILTER

  • RGB Primary Color Filter (Bayer Array)

IMAGING PROCESSOR

  • 2 x DIGIC DV 5

INTERCHANGEABLE LENS SYSTEM

  • Choice of PL or EF mounts for compatibility with a wide variety of lens systems.

ND FILTER

  • Standard: 2, 4, 6 Stops , Expanded: 2, 4, 6, 8, 10 Stops

EXPOSURE MODES

  • Manual
  • GAIN Normal Setting -2dB to 44 dB
  • Expanded  -6dB to 54dB

ISO

  • Standard: 160 to 25,600, Expanded: 100 to 102,400

SHUTTER SPEED RANGE

  • 59.94i/59.94p: 1/60 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/4, 1/8, 1/15, 1/30; CS: 59.94 – 250.70 Hz
  • 29.97p: 1/30 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/4, 1/8, 1/15; CS: 29.97 – 250.70 Hz
  • 23.98p/24p: 1/24 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12; CS: 23.97 – 250.70 Hz
  • 50i/50p: 1/50 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12 1/25; CS: 50.00 – 250.70 Hz
  • 25p: 1/25 to 1/2000 in 1/4 or 1/3 stops; SLS: 1/3, 1/6, 1/12; CS: 25.00 – 250.70 Hz

SHUTTER ANGLE SETTINGS

  • 59.94i/59.94p: 360, 240, 216, 180, 120, 90, 60, 45, 30, 22.5, 15, 11.25
  • 29.97p: 360, 240, 216, 180, 120, 108, 90, 60, 45, 30, 22.5, 15, 11.25
  • 23.98p/24p: 360, 345.6, 288, 240, 180, 172.8, 144, 120, 90, 86.4, 72, 60, 45, 30, 22.5, 15, 11.25
  • 50i/50p: 360, 300, 240, 180, 150, 120, 90, 60, 45, 30, 22.50, 15, 11.25
  • 25p: 360, 300, 240, 180, 150, 120, 90, 75, 60, 45, 30, 22.50, 15, 11.25

RECORDING OPTIONS

  • Resolution : 4096×2160 / 3840×2160 / 2048×1080 / 1920×1080
    Signal configuration : YCC422 10bit/(*)RG8444 (12bit/10bit)
    (*) Only with 2048×1080 or 1920×1080; 29.97P, 23.98P, 25.00P and 24.00P
  • Photo: JPEGResolution : 2048 x 1080, 1920 x 1080
  • XF AVC Video compression Formats: MPEG-4 AVC/H.264
  • Slow & Fast motion recording (max. 120 fps supported), frame recording, pre-recording, interval recording

FILE FORMAT

  • MXF

AUDIO

  • Linear PCM; 2-channel; 16/24-bit; 48 kHz 4-ch

EXTERNAL AUDIO INPUTS

  • 2 x XLR (auto and manual level settings), switchable between mic/line
  • 1 x 3.5mm microphone jack

DIMENSIONS

  • Approx. 5.9 x 7.2 x 7.2″ / 149 x 183 x 183 mm (without grip)
  • 7.5 x 7.2 x 7.4″ / 19.1 x 18.3 x 18.8 cm (with grip)

WEIGHT

  • 4 lbs. Body only, Over 7 lbs. with everything
